Creating and securing your reverse proxies with SWAG and Authelia

PTS

Sep 25, 2021 • 22 min read

Reverse proxies are a great way to access services and apps on your NAS when you're not on your local network. It's also a more secure way to allow others to access your website or service than giving them your public IP address and forwarding your ports through your router. In fact, that last option exposes your whole network to the world and it won't be long before you start seeing intrusion attempts.

Instead, we will use a method which means we only need to keep one, secure, port open.

With the uptake of https, and using a CDN like Cloudflare, you can now protect your public IP from prying eyes, and ensure connections are secure and authorized. We're not going to go into setting up Cloudflare in this article (I'm going to assume you've got your own fully qualified domain name (FQDN) and CDN already set up, and know how to create your A or CNAME records for your reverse proxies) but I will show you how to set up two services:

SWAG: a 3-in-1 service which acts as your nginx reverse proxy server, your SSL certificate requester via LetsEncrypt, and fail2ban jail server (fail2ban is a great tool which monitors attempted auths to your services, and bans IPs which fail to provide correct auth within a certain amount of attempts/time)
Authelia: an authorization service which will act as a single authorizer for your services

The way this works is relatively simple (though it may not look it at first). When your CDN receives a DNS query for your sub.domain.com and forwards it to your public IP, your nginx server sees that query, checks the app.subdomain.conf files and routes it to your app or container. So far so easy.

The app.subdomain.conf file also has an option to route the request through Authelia first. So when nginx receives the query, instead of just saying 'ok here's radarr' it goes 'hold up, this is meant to be sent to authelia first', sends it there, and only once the correct auth has been given by authelia will it then say 'ok, now I can send you to radarr'.

Enough of that, let's get these set up. You can jump to a specific part of the page by opening this drop down box:

Page Contents

Prepping for SWAG

Creating the SWAG container

If you're using Cloudflare

Reverse proxy prep

The auto-proxy docker mod

Creating your own proxy.conf file

Fail2Ban

Prepping for Authelia

Configuring Authelia

Using Authelia in your SWAG proxy.conf

SWAG

Prepping for SWAG

There are a few things you will need for SWAG to work effectively:

Knowledge of how to use docker-compose. If you don't, please read up on it here
Knowledge of using .env files to pass information to docker-compose. If you don't know how or don't want to use .env files, then remove anything in the below compose template that begins with a $ (dollar sign) and type in your own information for that variable
A pre-created folder already set up on your system which we will point our SWAG config at (make sure permissions are set up to allow docker to read/write to it)
A docker network created and ready (which I've called proxy)
The details for your certificate validation method (my example below uses DNS validation with Cloudflare as it's my CDN, which is doubly secure as DNS validation doesn't require port 80 to be open on my router for LetsEncrypt, which other methods do)
Port 443 forwarded from your router to your SWAG host machine - note that if you change the host port in the container setup below (say you use 444 instead) you will need to make sure that port 443 from your router is forwarded to port 444 on your host machine
The email address you registered or will use for your let's encrypt certificates
A Maxmind License Key if you want to use geoIP restrictions, such as allowing connections from Mongolia but not from Argentina (go to the maxmind website to create your free account and create your license, be sure to take note of it)
A general read of the SWAG documentation is always a good shout, you can find that here

💡

Since writing this article, linuxserver have modified the method used to do geoIP blocking (although it still requires the maxmind key mentioned above and included in the compose file below). You can visit this page in their documentation to read up on the steps needed to enable it

Creating the SWAG container

First up we're going to create our docker proxy network. SSH into your machine and type in:

sudo docker network create proxy

This creates the proxy network we will connect our SWAG container to.

Once that's done, copy and paste this template to create your docker-compose.yml file:

services:
  swag:
    image: ghcr.io/linuxserver/swag
    container_name: swag
    cap_add:
      - NET_ADMIN
    environment:
      - TZ=$TZ #change to your timezone
      - URL=$DOMAINNAME #change to the domain you want to protect with a certificate
      - SUBDOMAINS=wildcard
      - VALIDATION=dns
      - DNSPLUGIN=cloudflare
      - EMAIL=$EMAIL ADDRESS #change, can be any email address
      - ONLY_SUBDOMAINS=false
      - MAXMINDDB_LICENSE_KEY=$MAXMINDDB #remove if not necessary
      - DOCKER_MODS=linuxserver/mods:swag-cloudflare-real-ip|linuxserver/mods:swag-auto-reload|linuxserver/mods:universal-docker|linuxserver/mods:swag-auto-proxy #delete if not wanted or necessary
      # uncomment the next line if you plan to use the socket proxy
      #- DOCKER_HOST=socket-proxy
    volumes:
      - $DOCKERDIR/swag:/config #change before the `:` to your swag path
      #comment out the next line if you want to use a socket-proxy container
      - /var/run/docker.sock:/var/run/docker.sock:ro
    ports:
      - 443:443 #change before the ':' if necessary, take note of port-forwarding comment at point 6 above if you do change it
      - 80:80 #change before the ':' if necessary
    restart: unless-stopped
    networks:
      - proxy
      # uncomment the next line if you plan to use a socket-proxy
      #- socket_proxy

networks:
  proxy:
    external: true
  # uncomment the next two lines if you plan to use a socket proxy
  #socket_proxy:
    #external: true

port 80 isn't necessary if you are using DNS validation, so can be commented out if you prefer

💡

The above should work off the bat. I've included some commented lines however should you wish to use a socket.proxy container. If you're unsure of how to do that, follow the link here to set it up. You can then uncomment the relevant lines in the compose

Let's break this down a little:

URL is where you put your domain name, without any http, https or www
SUBDOMAINS can either be a list of your subdomains for which SWAG will request SSL certificates (i.e. SUDBOMAINS=radarr,sonarr,prowlarr,nextcloud etc.) OR as in the above, it can be a wildcard, which will request a *.domain.com certificate, good for each and every sub.domain.com you could want to create
VALIDATION and DNSPLUGIN are specific to your preferences, and it can be found in their documentation here
EMAIL is pretty self explanatory
ONLY_SUBDOMAINS can either be true or false. If true, it means that SWAG will only request the specified subdomain or wildcard certificate. If false, it will also request a domain.com certificate as well
DOCKER_MODS adds 3 very helpful tools, separated by the | character. The first allows your SWAG container to read actual incoming IPs rather than just see everything as originating from your container IP (this only works if you're using Cloudflare as your domain host). The second removes the need to completely restart the container when you make a change to a proxy.conf or other nginx-related files. The third (which requires the universal-docker and auto-proxy mods) allows SWAG to automatically create reverse proxies using labels
volumes, ports and networks should be self explanatory

To read more on docker mods click here

Preparation required for creating your first reverse proxy

💡

before doing this, I highly recommend you create your A or CNAME record for one or more of your services on your CDN. A good first option would be something like radarr or sonarr

Once you've created your compose file, create the container with docker-compose up -d and confirm that it's running.

If you're using Cloudflare

(If you're not, jump to here)

First we're going to change the cloudflare.ini file, which can be found inside the dns-conf directory. We need to do a few things:

locate the cloudflare.ini file and open it
locate the line dns_cloudflare_api_token and make sure it is uncommented (no # at the beginning of the line) and all other lines are commented (they do have a # at the beginning of the line

yours may look a little different depending on how the SWAG devs modify their sample files

click the link to begin the process of creating an API Token (login first, or click the link again if you needed to log in) and then follow the screenshots below

Click `Use template` on the top line for `Edit zone DNS`

Select your domain under `Zone Resources` and then click `Continue to summary` at the bottom of the page

the next screen will show your API token. Copy it and insert it into the API token line so that it looks like dns_cloudflare_api_token = randomtokenstring (spaces before and after the = may or may not be necessary)
restart your SWAG container to ensure that the changes have taken effect

Cloudflare and Certificates

For cloudflare to accept your cert through SWAG and make sure all connections are happy, there is another setting we need to configure on the Cloudflare site.

In the left hand panel, select SSL/TLS

Make sure you have 'Full` selected

Cloudflare and proxying your connection (orange cloud)

Once of Cloudflare's best features is that it will protect your public IP by proxying connections through one of its IPs. To make use of this, you need to do a few things.

On your Cloudflare DNS page, make sure you've toggled on the orange cloud which says 'Proxied' next to it

Navigate to your SWAG config files, and locate nginx.conf
Locate the http block, and inside the { } brackets, add the following lines:

    # docker mod cloudflare_real-ip
    real_ip_header X-Forwarded-For;
    real_ip_recursive on;
    include /config/nginx/cf_real-ip.conf;

I put it at the bottom, which means it looks like the screenshot below, but you can put it anywhere you want within the brackets:

Save the file, and restart SWAG (if necessary)

For all users

Navigate to the nginx folder and select the ssl.conf folder, ensuring that at least the following lines are uncommented, meaning the whole file should look like this:

# Certificates
ssl_certificate /config/keys/letsencrypt/fullchain.pem;
ssl_certificate_key /config/keys/letsencrypt/privkey.pem;
# verify chain of trust of OCSP response using Root CA and Intermediate certs
ssl_trusted_certificate /config/keys/letsencrypt/fullchain.pem;

# Diffie-Hellman Parameters
ssl_dhparam /config/nginx/dhparams.pem;

# Enable TLS 1.3 early data
ssl_early_data on;

# HSTS, remove # from the line below to enable HSTS
add_header Strict-Transport-Security "max-age=63072000; includeSubDomains; preload" always;

# Optional additional headers
#add_header Cache-Control "no-transform" always;
add_header Content-Security-Policy "upgrade-insecure-requests; frame-ancestors 'self'";
#add_header Referrer-Policy "same-origin" always;
add_header X-Content-Type-Options "nosniff" always;
#add_header X-Frame-Options "SAMEORIGIN" always;
#add_header X-UA-Compatible "IE=Edge" always;
add_header X-XSS-Protection "1; mode=block" always;

you can uncomment other optional headers if you know what you're doing

Save and close this file

💡

I always prefer having HSTS enabled, however some people may have use-cases where that's not necessary. Comment it again by putting a '#' in front of the line if you want

We shouldn't need to touch any other .conf files in this directory just yet. Instead, inside nginx, navigate to the proxy-confs directory, and take a look at all of the 'sample' .confs. These are what we and SWAG use to set up a reverse proxy

Creating a reverse proxy using the `auto-proxy` docker mod

Provided SWAG has a template service.subdomain.conf.sample file for the service you want to reverse proxy, you can use this method. If it doesn't, you'll need to jump to here.

I'm going to assume you followed the steps on my socket proxy article already. If you haven't, then you're going to need to add a volume mapping to your SWAG container:

    volumes:
      - /var/run/docker.sock:/var/run/docker.sock:ro

Either way, we're going to jump straight in and create our radarr container which will tell SWAG to configure the correct proxy.conf.

Check out the compose file below:

networks:
  default:
    name: proxy
    external: true

services:
  radarr: #movie search agent
    image: ghcr.io/linuxserver/radarr
    container_name: radarr
    environment:
      - PUID=$PUID
      - PGID=$PGID
      - TZ=$TZ
      - UMASK=022
    volumes:
      - $DOCKERDIR/Radarr:/config
      - $MEDIADIR:/media
    ports:
      - 7878:7878
    labels:
      - swag=enable
    restart: unless-stopped

It's a standard radarr compose file, but we've done a few things:

We've set the default network to be the same that SWAG uses, called proxy
We've added a label which, when SWAG scans the docker socket, enables it to see that radarr wants a proxy.conf

We can see this taking place in our SWAG logs:

**** Remote docker service socket-proxy will be used ****
s6-rc: info: service init-mod-universal-docker-setup successfully started
s6-rc: info: service init-mod-swag-auto-proxy-setup: starting
**** libmaxminddb already installed, skipping ****
**** Installing all mod packages ****
fetch http://dl-cdn.alpinelinux.org/alpine/v3.15/main/x86_64/APKINDEX.tar.gz
s6-rc: info: service init-mod-swag-cloudflare-real-ip-setup successfully started
fetch http://dl-cdn.alpinelinux.org/alpine/v3.15/community/x86_64/APKINDEX.tar.gz
**** Using preset proxy conf for radarr ****
s6-rc: info: service init-mod-swag-auto-proxy-setup successfully started
(1/1) Installing inotify-tools (3.20.11.0-r0)
Executing busybox-1.34.1-r7.trigger
OK: 252 MiB in 231 packages

Note line 9, Using preset proxy conf for radarr.

And that's it. It may need a few seconds to configure, and if you have many containers with the label it may take even longer, but you now have a working auto-proxy service.

Creating your reverse proxy using the template .conf file

This is what you'll need to do when it's not possible to use the auto-proxy mod.

Head over to whatever you set as your $DOCKERDIR/swag folder on your host machine. Via SMB in Windows, it should look something like this:

💡

Make sure your mapped directory has the relevant permissions for Docker to write to it, otherwise the above won't populate and your container won't start properly

We're going to stick with radarr as a reverse proxy, and I'm going to assume you've already set up your A or CNAME for it.

Locate the radarr.subdomain.conf.sample file which is in nginx->proxy-confs, and open it. You should see something like this:

## Version 2021/05/18
# make sure that your dns has a cname set for radarr and that your radarr container is not using a base url

server {
    listen 443 ssl;
    listen [::]:443 ssl;

    server_name radarr.*;

    include /config/nginx/ssl.conf;

    client_max_body_size 0;

    # enable for ldap auth, fill in ldap details in ldap.conf
    #include /config/nginx/ldap.conf;

    # enable for Authelia
    #include /config/nginx/authelia-server.conf;

    location / {
        # enable the next two lines for http auth
        #auth_basic "Restricted";
        #auth_basic_user_file /config/nginx/.htpasswd;

        # enable the next two lines for ldap auth
        #auth_request /auth;
        #error_page 401 =200 /ldaplogin;

        # enable for Authelia
        #include /config/nginx/authelia-location.conf;

        include /config/nginx/proxy.conf;
        include /config/nginx/resolver.conf;
        set $upstream_app radarr;
        set $upstream_port 7878;
        set $upstream_proto http;
        proxy_pass $upstream_proto://$upstream_app:$upstream_port;

    }

    location ~ (/radarr)?/api {
        include /config/nginx/proxy.conf;
        include /config/nginx/resolver.conf;
        set $upstream_app radarr;
        set $upstream_port 7878;
        set $upstream_proto http;
        proxy_pass $upstream_proto://$upstream_app:$upstream_port;

    }
}

your version number may be different depending on how long it's been since I wrote this article, and other changes may have been made - this is a guide only remember

Again let's break this down a little bit into the various blocks:

server: tells the SWAG container various things such as which port to listen in on and which subdomain will be forwarded by the CDN. It has options to uncomment for LDAP or Authelia integration (we'll come back to the Authelia stuff later on)

if you didn't set your A or CNAME record as radarr, but something like movies for instance, change this in server_name radarr.*; to server_name movies.*;

location block 1 and 2: we're interested only in the following (in both blocks):

    include /config/nginx/proxy.conf;
    include /config/nginx/resolver.conf;
    set $upstream_app radarr;
    set $upstream_port 7878;
    set $upstream_proto http;
    proxy_pass $upstream_proto://$upstream_app:$upstream_port;

you'll notice it's the same in both blocks

In fact, we're only interested in the following two lines:

    set $upstream_app radarr;
    set $upstream_port 7878;

these tell SWAG where to look for the service

If you've used the default container name and port when creating your radarr container, those being radarr and 7878, and you've got your radarr and SWAG containers on the same docker network then you don't need to change a thing
If however you did change your port or container name, then you need to reflect those changes here
If you have your SWAG and radarr containers on different docker networks, then where it says set $upstream_app radarr;, you must change radarr to the IP of your host machine, without any http or https such as 192.168.1.10

you need to make any required changes in both blocks

When you think you've got this ready to go, rename the file as radarr.subdomain.conf. Do not only save it, as the .sample on the end means that SWAG will not read it
You must now restart your SWAG container - any change to a .conf file will not be read other than at container start-up
You should now be able to go to radarr.yourdomain.com and access your radarr gui (or movies.yourdomain.com or whatever.yourdomain.com which matches the A or CNAME you set on your CDN)

And with that you've set up your first reverse proxy. Rinse and repeat for any and all other services. Note that some of the .sample files will have differences, either more or less dependent on the service's requirements.

You may also find that a .sample file doesn't exist for your specific service. In that case, choose one which you think will likely fit, make sure you change the name in the server_name part of the server block to your A or CNAME record, change the relevant parts of the location block(s) and it should work.

A few notes on Fail2ban

Some configuration is required for fail2ban to work in the way you want it to. The SWAG github repo has info here which I recommend reading, but essentially you will want to go through your jail.local in the fail2ban directory. It's worth noting that while 5 jails are included by default in the installation, but other jails can be added by creating their files with .local rather than .conf (the .conf files are recreated every time the container is restarted).

It's possible that your fail2ban instance may read every IP as the docker bridge network gateway it's on (i.e. 172.xx.xx.1). Specific to Synology, this link has a work around for iptables, but may be applicable to other systems. If you think you may get blocked by default, it's worth disabling your banaction in jail.local by commenting it out (putting a # in front of the line) until you're confident fail2ban is reading IPs correctly.

If you're proxying your domain behind Cloudflare, then everything will come through as one of Cloudflare's proxy IP addresses. While it's not going to block you, it also doesn't help you understand your real traffic, and again could just end up blocking Cloudflare's proxy and no external IP would be able to access your service. I've already included the dockermod in the docker-compose file for Cloudflare to pass the real IP to the container, however you also need to make a change to the nginx.conf file. Click here to get the instructions.

💡

It's also worth noting that IP obfuscation, either due to docker networking or proxying, will affect the accuracy of your GeoIP tracking via maxmind

Authelia

Now that you've set up your reverse proxy, you've decided you want to add some security to access it. Enter Authelia.

Buckle up, this will take a bit of time.

Prepping for Authelia

To create and run this container, you'll need the following prepped:

The ability to create a reverse proxy to your Authelia container (handy that you've just learnt how to do that from SWAG hey? Go search for the authelia.subdomain.conf.sample file)
The following folders set up in your $DOCKERDIR: authelia, and subdirectories inside called app, redis and sql
A docker network set up called auth

Creating the necessary containers

The below is a template compose which will create the Authelia service, as well as a database container, a database management container, and a redis container. If you already have a database container you want to use, you do not need to create them again in this stack, and the auth-mysql, auth-phpmyadmin and auth-redis services can be removed. I however like to have a completely separate database container for Authelia.

networks:
  auth:
    external: true
  proxy:
    external: true

services:
  authelia:
    image: authelia/authelia
    container_name: authelia
    ports:
      - 9091:9091 #change before the ':' as necessary
    environment:
      - PUID=$PUID #change to your user ID
      - PGID=$PGID #change to your group ID
    depends_on:
      - auth-redis
      - auth-mysql
    volumes:
      - $DOCKERDIR/authelia/app:/config/ #change `$DOCKERDIR` to your docker directory
    restart: unless-stopped
    networks:
      - auth
      - proxy

  auth-mysql:
    image: mysql:latest
    container_name: authelia_mysql
    volumes:
      - $DOCKERDIR/authelia/sql:/var/lib/mysql #change the local path to your NAS location where you want the DB data to live
    environment:
      - MYSQL_ROOT_PASSWORD=$MYSQLROOTPWD #enter a password for your main sql root user account
    ports:
      - 3306:3306 #change before the ':' as necessary
    restart: unless-stopped
    networks:
      - auth

  auth-phpmyadmin:
    image: phpmyadmin/phpmyadmin:latest
    container_name: authelia_php
    ports:
      - 81:80 #changed because we already used port 80 for SWAG
    environment:
      - PMA_PORT=3306 #enter the same port that you have your auth-mysql running on
      - PMA_HOST=auth-mysql
    restart: unless-stopped
    networks:
      - auth

  auth-redis:
    image: redis:latest
    container_name: authelia_redis
    volumes:
      - $DOCKERDIR/authelia/redis:/data #change the local path to your NAS location where you want the DB data to live
    ports:
      - 6379:6379 #change before the ':' as necessary
    restart: unless-stopped
    networks:
      - auth

make changes where indicated or necessary

Once more, let's break this down:

authelia - depends_on both the mysql and redis containers, meaning it won't start up unless they also have started up; networks to both auth and proxy, as it needs to communicate with SWAG as well
auth-mysql - the database container authelia will use, and sets up a root password to access the database server
auth-phpmyadmin - a container to create and manage individual databases and users in the mysql container
auth-redis - not 100% necessary, but will speed up request returns when authelia is invoked by SWAG

Note that we currently do not have any database configuration set up, or a way to pass user/password details to authelia. This will be set up in the next step

When you're ready, run your docker-compose up -d command, and watch your 4 containers being created. Once spun up, I would stop the authelia container, either through Portainer if you use it, or via the CLI.

Creating the mysql database and user for authelia

I've written an article about MySQL and phpMyAdmin here. Go through it and set up a database with a user, password and database name of your choice. For the sake of this walkthrough, I'm going to say that both the user and database name is 'authelia'. The password is your own.

when you are offered a choice of collation during the creation of the database, it's recommended to use utf8_bin

Setting the Authelia configuration

We now have all the information we need to modify the configuration.yml file which Authelia uses.

💡

UPDATE 2023/01: A change in the way Authelia reads the configuration.yml meant users trying to set things up the way I'd originally shown weren't having success. I've modified the configuration file below so new installations should work, however if for any reason you're having difficulties please drop a comment at the bottom of the page.

Existing working installations will continue to work, no changes are required.

Navigate to your $DOCKERDIR/authelia/app directory and open configuration.yaml. It's a rather long file, so below I'm going to include only the information which needs to be changed, and some of the information you shouldn't change, but overall it should now look like this:

---
###############################################################################
#                           Authelia Configuration                            #
###############################################################################

theme: dark

identity_validation:
  reset_password:
    jwt_secret: 123456789 #change this to at least a 32-character string

server:
  address: tcp://0.0.0.0:9091/authelia #do not change
  buffers:
    read: 8192
    write: 8192

log.level: info

totp:
  issuer: YOUR_DOMAIN.COM #such as auth.yourdomain.com
  period: 30
  skew: 1

authentication_backend:
  password_reset:
    disable: false #change to true if you want to stop users from resetting their passwords
  refresh_interval: 30m #I found that the default of 5 is too short
  file:
    path: /config/users_database.yml #don't change this
    password:
      algorithm: argon2id
      iterations: 1
      key_length: 32
      salt_length: 16
      memory: 1024
      parallelism: 8

access_control: #Recommend reading up on all the options for access control
  default_policy: deny
  #rule order matters
  networks:
    - name: internal
      networks: #uncomment (remove the #) the line(s) below which matches your internal network, or add your own (without the #)
        #- 192.168.0.0/24
        #- 192.168.1.0/24
        #- 10.0.0.0/24
  rules: #https://www.authelia.com/configuration/security/access-control/ for more rule examples
    ## bypass rule
    - domain: "auth.domain.com" #change to your issuer domain above
      policy: bypass

    ## catch-all
    #bypass authelia while on LAN
    - domain: "*.domain.com"
      networks:
        - internal
      policy: bypass

    #rules for everyone
    - domain: "*.domain.com"
      policy: one_factor

session:
  name: authelia_session #do not change
  cookies:
    - domain: YOURDOMAIN.com #change
      authelia_url: 'https://sSUB.YOURDOMAIN.com' #change
  same_site: lax
  secret: "YOUR_SESSION_SECRET" #make this a long strong, 26 characters or so
  expiration: 1h
  inactivity: 5m
  remember_me: 2M
  redis:
    host: authelia_redis #change to your host machine's IP if this doesn't work
    port: 6379 #if you use IP above, make sure this matches the mapped port
    password: "" #do not change. if this doesn't work, remove the "" and try again
    database_index: 0
    maximum_active_connections: 10
    minimum_idle_connections: 0

regulation:
  max_retries: 3
  find_time: 10m
  ban_time: 12h

storage:
  encryption_key: "YOUR_STORAGE_ENCRYPTION_KEY" #use a 20-character random string
  mysql:
    address: tcp://IP:3306 #change this to your host machine's IP and mapped port
    database: authelia
    username: authelia
    password: "YOUR_MYSQL_AUTHELIA_DB_PASSWORD" #the password you set for the database via phpMyAdmin

notifier: #you can only use one of smtp or filesystem. uncomment/comment below as necessary to choose which
  #filesystem:
    #filename: /config/notification.txt
  disable_startup_check: false
  #smtp:
    #username: YOUR@EMAIL.HERE
    #password: "YOUR_EMAIL_PASSWORD"
    #address: smtp.gmail.com:587 #change to match your smtp uri and port
    #sender: YOUR@EMAIL.HERE
    #subject: "[Authelia] {title}"
    #startup_check_address: test@authelia.com
    #disable_require_tls: false
    #disable_html_emails: false
    #tls:
      #skip_verify: false
      #minimum_version: TLS1.2
...

these items are important for the functionality of Authelia. Make sure hostnames for redis and mysql match the container names in the compose file, or use an IP

A quick note on SMTP as a notifier. If you use gmail, the notifier block is a lot simpler. Check out the authelia smtp page at the bottom to get that info, or to read up on what the rest of the block does.

💡

Some users have reported issues with the Notification Provider notifier, both when using filesystem and SMTP. If you experience this, comment out the filesystem and filename lines, and change disable_startup_check: to true

Creating your authelia users and passwords

The final thing we need to do is create your user(s) and password(s). In the configuration above, we specified that this will be done via a file, called users_database.yml. This is perfectly fine for a handful of users, say up to 10. If you have more than that, you may want to investigate LDAP, but for now...

In the same directory as your configuration.yml, create a users_database.yml file. The contents will take the following form:

users:
  user1:
    displayname: "username"
    password: "a long hashed password"
    email: #optional
    groups: #optional
      - a group name

  user2:
    displayname: "anotheruser"
    password: "another long hashed password"

etc.

To create the hashed password, we need to SSH into our machine and use the command line, where we copy and paste the following command for each user who needs a password:

docker run authelia/authelia:latest authelia hash-password 'yourpassword'

replace 'yourpassword` with a password

This will do a one-time run of the container, which will hash your password
You'll get an output on the next line of the password hash. For instance, if you kept the defaults as above, and used a password of 'authelia', you would type in:

docker run authelia/authelia:latest authelia hash-password authelia

and your resulting hash would be

$argon2id$v=19$m=65536,t=1,p=8$dnBiQ2NLdTB6d2hMakMvOA$Uk9qK8U9EFjYmfKMoAYhTvzM/oTbh+Ht5mev96TqvOo

you can read up more on hashed password algorithm tuning here and here if you're so inclined

Copy your whole password hash string and paste it in between the " marks for your user's password. So a user called authelia, who uses a password authelia, would have the following entry in the users_database.yml

users:
  authelia:
    displayname: "authelia"
    password: "$argon2id$v=19$m=65536,t=1,p=8$dnBiQ2NLdTB6d2hMakMvOA$Uk9qK8U9EFjYmfKMoAYhTvzM/oTbh+Ht5mev96TqvOo"

our full user setup

Authelia should now be fully configured and ready to use - you can now restart the container. When the container is running, you should be able to access your authelia front page by typing http://yourNASip:9091 into your browser, and see this:

When you type in your username authelia and password authelia, if it's all working, it will simply reload this screen. Congratulations!

There's one final step to protecting your radarr (and/or other) container with it.

Modifying the proxy-conf in SWAG to use Authelia

If you're using auto proxy, this is easy. Where you've got your swag=enable label, you simply add another, swag_auth=authelia so the labels part of your compose will look like:

    labels:
      - swag=enable
      - swag_auth=authelia

You can even bypass certain subfolders in your URI such as /api and /anotherSubfolderby adding a third label:

    labels:
      - swag=enable
      - swag_auth=authelia
      - swag_auth_bypass=/api,/anotherSubfolder

If however you don't use the auto-proxy or the container in question doesn't have a proxy.conf template, you'll need to do the below.

Let's head back to our SWAG directory, and the nginx folder. You'll notice that there are two files, called authelia-location.conf and authelia-server.conf. If you have kept things as above, you shouldn't need to change anything in these files, however I bring them up so you understand what is referenced in the next steps.

Locate your radarr.subdomain.conf file inside the nginx>proxy-confs directory
Inside the first server block, locate the lines # enable for Authelia and #include /config/nginx/authelia-server.conf;
Uncomment (remove the #) the line include /config/nginx/authelia-server.conf;
Inside the first location block, locate the similar lines # enable for Authelia and #include /config/nginx/authelia-location.conf;
Uncomment the line #include /config/nginx/authelia-location.conf;
Save the file and restart the SWAG container
Now when you access radarr.yourdomain.com you should see a the same authelia login screen as above
Type in your username and password, and you will be sent through to your radarr gui

Happy authenticating!

Page Contents

SWAG

Prepping for SWAG

Creating the SWAG container

Preparation required for creating your first reverse proxy

If you're using Cloudflare

Cloudflare and Certificates

Cloudflare and proxying your connection (orange cloud)

For all users

Creating a reverse proxy using the auto-proxy docker mod

Creating your reverse proxy using the template .conf file

A few notes on Fail2ban

Authelia

Prepping for Authelia

Creating the necessary containers

Creating the mysql database and user for authelia

Setting the Authelia configuration

Creating your authelia users and passwords

Modifying the proxy-conf in SWAG to use Authelia

Related Article

Creating a reverse proxy using the `auto-proxy` docker mod
